Dozer  D60 D65P-7 Blade Lift Cylinder Repair Seal Kit 144-63-05020 1446305020

Product Description

Dozer D60 D65P-7 Blade Lift Cylinder Repair Seal Kit 144-63-05020 1446305020
 The product design of GUKE oil seal is excellent, the production process is exquisite, the product performance is good, the precision is high,combined with the strict inspection process, has been recognized by a large number of customers in the market.
   We use high quanlity raw materials from Gemany and Japen.
   We also sell other brand of seals such as NOK,Parker,SKF,Hallite,PET ,YCC,NAK and so on .


Parts List:


Pos.	Part No	Parts name	Qty
	144-63-13502	CYLINDER ,L.H.	1
	144-63-13500	CYLINDER ,L.H.	1
	144-63-13602	CYLINDER ,R.H.	1
	144-63-13600	CYLINDER ,R.H.	1
1.	144-817-8114	CYLINDER,L.H.	1
1.	144-817-8124	CYLINDER,R.H.	1
2.	144-60-15431	BUSHING	2
3.	07145-00055	SEAL,DUST	2
4.	144-60-15450	BUSHING	2
5.	144-60-12130	HEAD,CYLINDER	1
6.	07177-06530	BUSHING	1
7.	707-51-65110	PACKING,ROD	1
8.	07000-12105	O-RING OEM	1
9.	07146-02106	RING,BACK-UP	1
10.	01010-52055	BOLT	4
11.	01602-22060	WASHER	4
12.	144-63-12230	GLAND	1
13.	07177-06515	BUSHING	1
14.	144-63-92170	SEAL,DUST	1
15.	07179-00088	RING,SNAP	1
16.	07000-03078	O-RING OEM	1
17.	01010-51450	BOLT	2
18.	01602-21442	WASHER	2
19.	144-63-13320	ROD,PISTON	1
20.	144-63-13370	CAP	1
21.	07137-04006	BUSHING	1
21	07137-00040	SEAL,DUST	2
22.	07000-03040	O-RING	2
23.	01010-82085	BOLT	4
	144-63-13271	PISTON SUB	1
	144-63-92360	PISTON SUB	1
28.	707-44-11080	RING,PISTON	1
29.	07155-01125	RING,WEAR	1
30.	144-63-13161	RETAINER	2
30.	707-40-11090	RETAINER	2
31.	130-63-12761	PIN	2
32.	144-63-12360	NUT	1
33.	144-817-8312	TUBE,L.H.	1
33.	144-817-8322	TUBE,R.H.	1
34.	144-817-8335	TUBE,L.H.	1
34.	144-817-8345	TUBE,R.H.	1
35.	01010-51055	BOLT	4
36.	01010-51050	BOLT	4
37.	01602-21030	WASHER	8
38.	07000-13035	O-RING	2
39.	07283-13442	CLIP	4
40.	01599-01011	NUT	8
41.	01643-21032	WASHER	8
42.	144-817-8351	PLATE	1
GUKE WWW.SEALSKIT.COM

Application Chart:








Our Advantages
1, Focus on the development and manufacture of Hydraulic Cylinder Seal Kits more than 10 years.
2, A great number standard parts in stock.
3, Customized seal service.
4, CNC Machining Seals without mould cost ,fast dispatch.
5, All of seals the inner diameter from 0.2mm to 3500mm can be produced.
6, Seals solutions and technical support.
7, 24 hours online service.
