Product Details:
|
|
| Place of Origin: | CN |
|---|---|
| Brand Name: | GUKE NOK |
| Certification: | ISO9001 |
| Model Number: | CX350B CX350C CX330 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 kit |
| Price: | Negtiation |
| Packaging Details: | PP bag inside Carton box outside |
| Delivery Time: | 3-7 days after payment |
| Payment Terms: | T/T, Western Union,Paypal,Xtransfer |
| Supply Ability: | 500 kits per Week |
|
Detail Information |
|||
| Part Name: | Excavator CX350B CX350C CX330 Bucket Cylinder Seal Kit | Part No: | LZ007310 |
|---|---|---|---|
| Material: | PU+PTFE+NBR+IRON+ Phenolic | Size: | Standar Size |
| OEM/ODM: | Accept | Condition: | 100% New |
| Appliion: | Excavator Hydrulic Cylinder | Feature: | High Cost Performance Heat Resistance Oil Resistance Presure Resistance |
| High Light: | CX330 Bucket Cylinder Seal Kit,CX350B Bucket Cylinder Seal Kit,LZ007310 Bucket Cylinder Seal Kit |
||
Product Description
Excavator CX350B CX350C CX330 Bucket Cylinder Seal Kit LZ007310
The product design of GUKE oil seal is excellent, the production process is exquisite, the product performance is good, the precision is high, combined with the strict inspection process, has been recognized by a large number of customers in the market.
We use high quanlity raw materials from Gemany and Japen.
We also sell other brand of seals such as NOK,Parker,SKF,Hallite,PET ,YCC,NAK and so on .
| Product Overview | |
| Name: | Excavator CX350B CX350C CX330 Bucket Cylinder Seal Kit |
| Condition | 100% New |
| Material: | PU+PTFE+NBR+IRON+ Phenolic |
| Machine Model: | Excavator CX350B CX350C CX330 |
| Part Number: | LZ007310 |
| Size: | Standard Size Custom Size |
| Hardness: | 92degree |
| Temparature: | -40 ℃To 110 ℃ |
| Feature: | Oil Resistance,Heat Resisitance,Pressure resisitant |
| Certifiion: | ISO 9001 |
| Raw Material: | HUNTSMAN of German ZEON of Japan |
| OEM: | Accpetable |
| vailablity: | In Stock |
| Shipping: | Express,By Air,By Sea |
Parts Li
| d | PartNo | Qty | Partsname |
| 1 | KSV1928 | 1 | BUCKETCYLINDER |
| 1 | KSV18700R | 1 | REMAN-HYDCYLINDER |
| 1 | KSV18700C | 1 | CORE-HYDCYLINDER |
| 2 | LU002310 | 1 | CYLINDERENDCAP |
| 3 | LK005170 | 1 | BUSHING |
| 4 | LA010340 | 1 | BACK-UPRING |
| 5 | LH004570 | 1 | PLASTICRING |
| 6 | LJ013590 | 1 | PLUNGER |
| 7 | LJ013620 | 1 | JACKPISTON |
| 8 | LE012290 | 2 | RING |
| 9 | LV00039 | 1 | SCREW |
| 10 | LA010320 | 1 | SCREW |
| 11 | LR013250 | 1 | HYDTUBE |
| 12 | LR013280 | 1 | HYDTUBE |
| 13 | LA010360 | 2 | COLLAR |
| 14 | LS002770 | 2 | SUPPORT |
| 15 | LA010270 | 4 | BOLT |
| 16 | LA010280 | 4 | WASHER |
| 17 | LA010250 | 4 | BOLT |
| 18 | LA010280 | 4 | WASHER |
| 19 | LA010220 | 12 | BOLT |
| 20 | LA010290 | 12 | WASHER |
| 21 | LA010180 | 4 | BOLT |
| 22 | LA00957 | 4 | WASHER |
| 23 | 153630A1 | 2 | LUBENIPPLE |
| 24 | LA009970 | 4 | BOLT |
| 25 | LA010070 | 4 | WASHER |
| 26 | LD001260 | 2 | CLAMPBRACKET |
| 27 | LZ007310 | 1 | SEALKIT |
| 28 | NSS | 1 | NOTSOLDSEPARAT |
| 29 | NSS | 1 | NOTSOLDSEPARAT |
| 30 | NSS | 1 | NOTSOLDSEPARAT |
| 31 | NSS | 1 | NOTSOLDSEPARAT |
| 32 | 154796A1 | 1 | O-RING |
| 33 | NSS | 2 | NOTSOLDSEPARAT |
| 34 | 154796A1 | 1 | O-RING |
| 35 | NSS | 2 | NOTSOLDSEPARAT |
| 36 | KHA10120 | 1 | O-RING |
| 37 | NSS | 1 | NOTSOLDSEPARAT |
| 38 | NSS | 2 | NOTSOLDSEPARAT |
| 39 | 154548A1 | 2 | O-RING |
| 40 | NSS | 2 | NOTSOLDSEPARAT |
| 41 | NSS | 2 | NOTSOLDSEPARAT |
| 42 | LB011000 | 1 | PISTONROD |
| 42A. | KSV1317 | 1 | SELFLUBRING |
| 43 | LR013360 | 1 | HYDCYLSLEEVE |
| 43A. | KSV1332 | 1 | SELFLUBRING |
| GUKE WW.SEALSKIT.COM | |||
Application Chart:
Our Advantages
1, Focus on the development and manufacture of Hydraulic Cylinder Seal Kits more than 10 years.
2, A great number standard parts in stock.
3, Customized seal service.
4, CNC Machining Seals without mould cost ,fast dispatch.
5, All of seals the inner diameter from 0.2mm to 3500mm can be produced.
6, Seals solutions and technical support.
7, 24 hours online service.
