Product Details:
|
|
| Place of Origin: | CN |
|---|---|
| Brand Name: | GUKE |
| Certification: | ISO9001 |
| Model Number: | Mechanical Caterpillar Truck 740 735 740B |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 kit |
| Price: | Negtiation |
| Packaging Details: | PP bag inside Carton box outside |
| Delivery Time: | 3-7 days after payment |
| Payment Terms: | T/T, Western Union,Paypal,Xtransfer |
| Supply Ability: | 500 kits per Week |
|
Detail Information |
|||
| Part Name: | Floating Seal For Mechanical 740 735 740B | Part No: | 363-4457 3634457 363-4454 3634454 |
|---|---|---|---|
| Material: | Steel 100cr6/Gcr15/ Cast 15CR3MO | Size: | Standar Size |
| OEM/ODM: | Accept | Condition: | 100% New |
| Appliion: | Excavator Or Dump Truck Or Engine | Feature: | High Cost Performance Heat Resistance Oil Resistance Presure Resistance |
| Highlight: | 363-4457 Floating Seal,3634454 Floating Seal |
||
Product Description
Floating Seal For Mechanical 740 735 740B 363-4457 3634457 363-4454 3634454
The product design of GUKE oil seal is excellent, the production process is exquisite, the product performance is good, the precision is high, combined with the strict inspection process, has been recognized by a large number of customers in the market.
We use high quanlity raw materials from Gemany and Japen.
We also sell other brand of seals such as ,Parker,SKF,Hallite,PET ,YCC,NAK and so on .
| Product Overview | |
| Name: | Floating Seal For Mechanical 740 735 740B |
| Condition | 100% New |
| Material: | Steel 100cr6/Gcr15/ cast 15CR3MO |
| Machine Model: | Mechanical 740 735 740B |
| Part Number: | 363-4457 3634457 363-4454 3634454 |
| Size: | Standard Size Custom Size |
| Hardness: | 58-62HRC /62-70 HRC |
| Temparature: | -40 ℃To 110 ℃ |
| Feature: | Oil Resistance,Heat Resisitance,Pressure resisitant |
| Certifiion: | ISO 9001 |
| Raw Material: | High Quality Steel |
| OEM: | Accpetable |
| vailablity: | In Stock |
| Shipping: | Express,By Air,By Sea |
APPLICATION CHART
PARTS LIST
| Pos. | Part No | Qty | Parts name |
| 1 | 2P-1823 | 1 | CUP-BEARING (TAPERED ROLLER) |
| 2 | 2P-1824 | 1 | CONE-BEARING (TAPERED ROLLER) |
| 3 | 9M-2744 | 1 | CONE-BEARING (TAPERED ROLLER) |
| 4 | 1A-1135 | 20 | BOLT (5/8-11X2-IN) |
| 5 | 1M-6573 | 1 | CUP-BEARING (TAPERED ROLLER) |
| 6 | 1P-3958 | 6 | ROLLER AS-SPECIAL |
| 7 | 2D-0604 | 1 | BUTTON |
| 8 | 2R-0239 | 1 | SEAL-O-RING |
| 9 | 2V-5656 | 1 | RING-SNAP |
| 10 | 2V-7092 | 1 | PLATE-RETAINER |
| 11 | 2V-7390 B | 1 | SHIM PACK (INCLUDES 15-SHIMS) |
| 12 | 2V-7398 | 3 | RING-RETAINING |
| 13 | 4V-4500 | 3 | SPACER (51X66X5-MM THK) |
| 14 | 4V-4504 | 1 | GEAR-RING (65-TEETH) |
| 15 | 4V-5233 | 6 | WASHER-THRUST (48X80X1.6-MM THK) |
| 16 | 4V-5234 | 6 | WASHER-THRUST (48X80X1.52-MM THK) |
| 17 | 4V-5237 | 1 | CARRIER-PLANETARY |
| 18 | 5P-2861 | 1 | SEAL-O-RING |
| 19 | 165-4929 | 2 | PLUG AS-MAGNETIC |
| (EACH INCLUDES) | |||
| 7M-8485 | 1 | SEAL-O-RING | |
| 5P-4484 | 1 | PLUG-MAGNETIC (FINAL DRIVE OIL DRAIN) | |
| 20 | 147-1206 | 3 | GEAR (23-TEETH) |
| 21 | 190-3593 | 3 | SHAFT-PLANETARY |
| 22 | 217-6309 Y | 1 | BRAKE GP-SERVICE |
| 23 | 218-8117 | 1 | SPINDLE |
| 24 | 301-2806 | 1 | COVER |
| 25 | 309-7664 | 1 | SEAL GP-DUO-CONE |
| 5P-1606 | 2 | RING-TORIC | |
| 26 | 317-1300 | 1 | HUB AS |
| 26A. | 2V-5715 | 1 | BUSHING-TERMINAL |
| 27 | 363-4457 Y | 1 | KIT-SEAL (HEAVY-DUTY DUAL FACE SEAL) |
| 28 | 376-0969 | 1 | WHEEL |
| 29 | 0S-1585 | 6 | BOLT (1/2-13X1.5-IN) |
| 30 | 0S-1594 | 6 | BOLT (3/8-16X1-IN) |
| 31 | 321-7848 | 27 | STUD-WHEEL |
| 32 | 5P-8245 | 6 | WASHER-HARD (13.5X25.5X3-MM THK) |
| 33 | 5P-8247 | 20 | WASHER-HARD (17X32X3.5-MM THK) |
| 34 | 7K-6058 | 8 | BOLT-12 POINT HEAD (1/2-13X2.5-IN) |
| 36 | 8D-2714 | 1 | SEAL-O-RING |
| B | USE AS REQUIRED | ||
| Y | SEPARATE ILLUSTRATION |
Our Advantages
1, Focus on the development and manufacture of Hydraulic Cylinder Seal Kits more than 10 years.
2, A great number standard parts in stock.
3, Customized seal service.
4, CNC Machining Seals without mould cost ,fast dispatch.
5, All of seals the inner diameter from 0.2mm to 3500mm can be produced.
6, Seals solutions and technical support.
7, 24 hours online service.
